BIM/CAD Library

Library for AutoCAD and Revit

OSMA, the largest Czech manufacturer of plastic piping systems, has completed a comprehensive library of 2D and 3D models for AutoCAD and is making it available to designers and architects free of charge.

The elements were designed so that anyone can work with them: standard blocks for AutoCAD Release 14 and later, as well as dynamic blocks for AutoCAD 2007 and later, in both 2D and 3D, and in three language versions. Since the BIM platform is not only popular today but also increasingly required, a new library of families for Revit has been added—HT System Plus and KG System PVC.

What You'll Find in the Library

polypropylene base piping, resistant to high temperatures and chemical exposure→unplasticized PVC pipe with SN4 circular stiffness→Pipes and fittings made of mineral-filled polypropylene significantly reduce noise→unplasticized PVC pipe with SN4 circular stiffness→Manhole bases and street inlets made of polypropylene with high ring stiffness→Pipes and fittings resistant to boiling water and the effects of light→

Library for ArchiCAD

For projects created in ArchiCAD, we offer a library with the same scope—all five product lines that you’ll most commonly encounter in both residential and outdoor sewer systems.

polypropylene base piping, resistant to high temperatures and chemical exposure→unplasticized PVC pipe with SN4 circular stiffness→Pipes and fittings made of mineral-filled polypropylene significantly reduce noise→unplasticized PVC pipe with SN4 circular stiffness→Manhole bases and street inlets made of polypropylene with high ring stiffness→Pipes and fittings resistant to boiling water and the effects of light→

TechCON OSMA-CAD Design Software

TechCON OSMA-CAD is a modern graphical calculation software for designing and processing residential sewer system projects in Windows. It includes all Ostendorf product lines—OSMA—and is free; after installation, simply complete the registration process.
